The Laser S183-8288 injector removal kit is designed to remove Ford EcoBlue diesel injectors in one go.
Previously, EcoBlue injectors could only be removed by breaking the fuel return connection and Piezo head apart, rendering the injector unusable.
This kit allows you to remove these injectors without having to break the injector apart first.

To remove diesel injectors in one go, allowing them to be reinstalled.
Fits: Ford Edge, Focus, Galaxy, S-Max (from 2018); Kuga, Mondeo, Ranger (from 2019); Tourneo and Transit (from 2016).
For engines: 2.0 litre EcoBlue diesel engines.
Equivalent to Ford OEM 303-1706.
The applied torque must not exceed 250 Nm.
Manufactured in Sheffield, England.
UK Registered Design.

IMPORTANT: Ensure that the lead screw is properly lubricated with Molybdenum Disulphide grease before use!
NOTE: If the nozzles are firmly attached and cannot be removed with the tool provided, please refer to Laser Part No. 7912.
